Specifications – HP DesignJet T600 Series
For more information on the HP DesignJet T600 Series, view the brochure.
| DesignJet T630 | DesignJet T650 |
|---|
| PRINT SPEED | 30 sec/page on D, 76 D prints per hour | 24-in: 26 sec/page on D, 81 D prints per hour; 36-in: 25 sec/page on D, 82 D prints per hour |
|---|---|---|
| PRINT RESOLUTION | Up to 2400 x 1200 optimized dpi | |
| TECHNOLOGY | HP Thermal Inkjet | |
| MARGINS | Roll: 0.2 x 0.2 x 0.2 x 0.2 in (5 x 5 x 5 x 5 mm) Sheet: 0.2 x 0.2 x 0.2 x 0.2 in (5 x 5 x 5 x 5 mm) | |
| INK TYPES | Dye-based (C, M, Y); pigment-based (K) | |
| PAGE YIELD | 20 ml of ink yields 101 A1/D pages, taking into account maintenance routines | |
| INK DROP | 5.5 pl (C, M, Y); 12 pl (K) | |
| PRINTHEADS | 1 (cyan, magenta, yellow, black) | |
| PRINTHEAD NOZZLES | 1376 | |
| LINE ACCURACY | ±0.1% | |
| MINIMUM LINE WIDTH | 0.0008 in (0.02 mm) | |
| MAX OPTICAL DENSITY | 8 L* min/2.10 D | |
| MEDIA | ||
|---|---|---|
| HANDLING | Sheet feed, roll feed, automatic sheet feeder, media bin, automatic horizontal cutter | |
| ROLL SIZE | 24-in: 11 to 24 in (279 to 610 mm) 36-in: 11 to 36 in (279 to 914 mm) | |
| SHEET SIZE | Auto sheet feeder: 8.3 x 11 to 13 x 19 in 24-in manual feed: 8.3 x 11 to 24 x 74.7 in 36-in manual feed: 8.3 x 11 to 36 x 74.7 in | |
| STANDARD SHEETS | Auto sheet feeder: A, B 24-in manual feed: A, B, C, D 36-in manual feed: A, B, C, D, E | |
| GRAMMAGE | 60 to 280 g/m² (roll/manual feed); 60 to 220 g/m² (auto sheet feeder | |
| THICKNESS | Up to 11.8 mil | |
| APPLICATIONS | Line drawings; Presentations; Renderings | |
| MEMORY | 1 GB | |
| HARD DISK | None | |
| CONNECTIVITY | ||
|---|---|---|
| INTERFACES | Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11 | |
| PRINT LANGUAGES (STANDARD) | HP-GL/2, HP-RTL, CALS G4, JPEG, URF | |
| DRIVERS | Raster driver for Windows and macOS | |
| DIMENSIONS (W X D X H) | ||
|---|---|---|
| PRINTER | 24-in: 39.9 x 23.8 x 36.7 in (1013 x 605 x 932 mm) 36-in: 51.9 x 23.8 x 36.7 in (1317 x 605 x 932 mm) | |
| SHIPPING | 24-in: 45.5 x 22.6 x 18.1 in (1155 x 575 x 475 mm) 36-in: 57.9 x 22.6 x 23.2 in (1470 x 575 x 590 mm) | |
| WEIGHT | ||
|---|---|---|
| PRINTER | 24-in: 63.7 lb (28.9 kg) 36-in: 76.5 lb (34.7 kg) | 24-in: 65 lb (29.5 kg) 36-in: 78 lb (35.4 kg) |
| SHIPPING | 24-in: 82.5 lb (37.4 kg) 36-in: 121.9 lb (55.3 kg) | 24-in: 83.8 lb (38 kg) 36-in: 123.5 lb (56 kg) |
| HP SOFTWARE AND SOLUTIONS | HP Click, HP Smart app, HP Print Preview for Windows, HP Easy Start, HP DesignJet Utility for Windows, HP Support Assistant | |
| REMOTE PRINT ENABLED | Yes | |
| ONE-CLICK MULTI-SIZE PRINTING | Yes | |
| ENVIRONMENTAL RANGES | ||
|---|---|---|
| RECYCLED PLASTIC IN PRINTER | 30% | |
| OPERATING TEMPERATURE | 41 to 104ºF (5 to 40ºC) | |
| OPERATING HUMIDITY | 20 to 80% RH | |
| OPERATING ALTITUDE | Up to 9843 ft | |
| STORAGE TEMPERATURE | -13 to 131ºF (-25 to 55ºC) | |
| ACOUSTICS | ||
|---|---|---|
| SOUND PRESSURE | 42 dB(A) (operating), < 16 dB(A) (idle) | |
| SOUND POWER | >5.8 B(A) (operating), < 3.4 B(A) (idle) | |
| POWER | ||
|---|---|---|
| CONSUMPTION | < 35 W (printing), < 5.6 W (ready), < 2.1 W (sleep), < 0.2 W (standby) | |
| REQUIREMENTS | Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 1200 mA max | |
| CERTIFICATION | ||
|---|---|---|
| SAFETY | USA and Canada (CSA certified) | |
| ELECTROMAGNETIC | Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES) | |
| ENVIRONMENTAL | ENERGY STAR; WEEE; ErP; EPEAT Gold | |
| WARRANTY | One-year limited hardware warranty | |
