Specifications – KIPFold 2800
See below the specifications for the KIPFold 2800, learn more about this product in the brochure.
| Features |
|---|
| One-Step Fold Packet Selection from KIP PrintPro, KIP PrintPro.NET, KIP Windows & AutoCAD HDI Drivers |
| All Folding Packet Standards Come “Pre-Set” in the KIP Print Management Suite |
| Folding at Rated Full Engine Speed |
| Wide Range of Folding Parameters – European, US & International Standards |
| Adjustable Media Bridge/Flat Stacker – Stacking on Bridge Reduces Operational Costs |
| Manual Feed/Offline Folding (Adjustable Feed Rail for Precision Offline Folding) |
| Stacker Full Notification – Bi-directional Notification to the User through KIP Touchscreen & Software |
| KIPFold | |
|---|---|
| COMPATIBLE BLACK & WHITE PRINT SYSTEMS | 7170K, 7570K, 7580K, 7590K, 7980K, 7990K |
| COMPATIBLE COLOR PRINT SYSTEMS | 860, 870, 880, 890, 970, 980, 990 (Printer productivity may be reduced based on the page size and fold packet requirements) |
| FOLD TECHNOLOGY – (ROLLERS-BLADE) | Media transportation via roller with precise blade action folding for creating tight folded packets |
| MEDIA WIDTH | 11″ – 36″ / 297 mm – 920 mm US – International Standard Sizes |
| MEDIA WEIGHT | 16 – 28 lb. / 60 -110 gms (Max Accuracy 20-24 lb.) |
| FOLD SPEED | Variable 4.8 – 29 m/min – Dependent on Printer Speed |
| FOLD STYLES | DIN, AFNOR, ISO, ARCH, ANSI, JAPAN STD + Customizable Sizes |
| FOLDED PACKET STACKING | 215 ‘D’ Size / 215 ‘A1” Size or 650 Linear Feet / 200 Linear Meters |
| UNFOLDED STACKING (FLAT SHEET) | Up to 100 standard size pages (on bridge) |
| PACKET SIZE: FAN FOLD | 6.3″-12″ adjustable in 0.01″ increments / 160 mm – 300 mm adjustable in 1 mm increments |
| PACKET SIZE: CROSS FOLD | 8 -12″ adjustable in 0.01″ increments / 200 mm – 310 mm adjustable in 1 mm increments |
| DOCUMENT LENGTH – CROSS FOLD | 98.42″ / 2,500 mm (15 Panels) |
| DOCUMENT LENGTH – FAN FOLD | 19′ 6″ / 6,000 mm (30 panels – 80 gsm) |
| MARGINS | 0″ – 4″ adjustable in 0.01″ increments / 0 mm – 99 mm adjustable in 1mm increments |
| TITLE BLOCK | Available with DIN or Inverse Packet Styles |
| FAN FOLD TRAY STACKING CAPACITY | 1 to 20 – Dependent on number of fan fold panels |
| WEB INTERFACE | Web Browser Enabled Diagnostics |
| Environmental | |
|---|---|
| POWER REQUIREMENTS | 100 – 240Vac 50/60Hz / 10A @ 115v / 6A @ 230v |
| ELECTRICAL RECEPTACLE | Based on local standards – supplied with KIPFold 2800 |
| POWER CONSUMPTION | Standby: 30W Max: 300W at 230 Volts |
| ACOUSTIC NOISE | 61 dB |
| WEIGHT WITHOUT TAB | 628 lbs. uncrated / 772 lbs. crated |
| WEIGHT WITH TAB | 723 lbs. uncrated / 866 lbs. crated |
| FOLDER DIMENSIONS | 64″x 48″x 70″ / 1634 mm x 1227 mm x 1178 mm – Including Bridge / No Options |
| CRATE DIMENSIONS | 43″x 53″x 75″ / 1100 mm x 1350 mm x 1900 mm – Bridge Detached |
| SAFETY APPROVALS | TÜV |
| Options | |
|---|---|
| FIELD UPGRADABLEUnlimited Length Fanfold (Based on print system capability) | |
