Specifications – KIP 2300
See below the specifications for the KIP 2300, learn more about this product in the brochure.
| SCANNER TYPE | C.C.D. with Super-Speed USB3 Technology and KIP RTT Technology |
|---|---|
| SCAN RESOLUTION | 600 x 600 dpi optical resolution |
| SCAN SPEED | Up to 12 ips / 305 mm per second (B & W) |
| Up to 6 ips / 152 mm per second (Color) | |
| SCAN FORMATS | TIFF, Multipage TIFF, PDF, PDF-A, Multipage PDF, DWF, Multipage DWF, JPEG, CALS |
| SCAN DESTINATION | Local USB (Removable Media), Unlimited IPS Mailboxes (Local), Unlimited FTP, Unlimited SMB |
| ORIGINAL SIZE WIDTH/LENGTH | Originals Up to 42″ – 36″ / 1,066 mm – 914 mm Scan width |
| ORIGINAL THICKNESS | Up to .6″ / 16 mm Automatic thickness detection |
| ORIGINAL FACE UP/FACE DOWN | Both – Dual Original Feed Tables |
| INTERFACE | USB 3.0, Super-Speed USB3 Technology (5 GB per sec data transfer) |
| DIMENSIONS | 55” W x 21” D x 11” H / 1,399 mm W, 480 mm D, 310 mm H |
| WEIGHT | 160 lbs / 73 kg |
| ELECTRICAL | 100-240V AC 50/60 Hz |
| POWER CONSUMPTION | < 120 W |
| MINIMUM PC REQUIREMENTS | Quad Core Processor ( such as an Intel i5 or higher ) |
| Windows 10 8GB RAM | |
| 1 TB Hard Drive | |
| 1 Gig RJ45 LAN Port | |
| One USB 3.0 Port (scanner connection) | |
| 27” Wide Screen Flat panel monitor | |
| USB keyboard and mouse |
