Specifications – Dynabook A-Series
Learn more about the Sharp Dynabook A-Series of laptops.
PROCESSORIntel® Core™ i5-7200U processor (2.5GHz, up to 3.1GHz, 3M Cache)
Intel® Core™ i5-7300U vPRO processor (2.6GHz, up to 3.5GHz, 3M Cache)
Intel® Core™ i7-7500U vPRO processor (2.7GHz, up to 3.5GHz, 4M Cache)
Intel® Core™ i7-7600U vPRO processor (2.8GHz, up to 3.9GHz, 4M Cache)Intel® Core™ i3-7100U processor (2.3GHz, 3M Cache)
Intel® Core™ i5-7200U processor (2.5GHz, up to 3.1GHz, 3M Cache)
Intel® Core™ i5-7300U vPRO processor (2.6GHz, up to 3.5GHz, 3M Cache)
Intel® Core™ i7-7600U vPRO processor (2.8GHz, up to 3.9GHz, 4M Cache)
| MODEL | Portégé A30 | Tecra A40 | Tecra A50 |
|---|---|---|---|
| OPERATING SYSTEM | Windows 10 Professional 64-bit | ||
| CHIPSET | Integrated with the Processor | ||
| MEMORY | 2 main memory slots, configurable up to max. 32GB DDR4 2133MHz | ||
| DISPLAY | 13.3″ HD Anti-Glare LED Backlight TFT display (16:9), resolution 1,366 x 768 13.3″ Full HD Anti-Glare LED Backlight TFT display (16:9), resolution 1,920 x 1,080 13.3″ Full HD Anti-Glare LED Backlight TFT display (16:9), with 10-finger capacitive touch support, resolution 1,920 x 1,080 | 14.0″ HD Anti-Glare LED Backlight TFT display (16:9), resolution 1,366 x 768 14.0″ Full HD Anti-Glare LED Backlight TFT display (16:9), resolution 1,920 x 1,080 | 15.6″ HD Anti-Glare LED Backlight TFT display (16:9), resolution 1,366 x 768 15.6″ Full HD Anti-Glare LED Backlight TFT display (16:9), resolution 1,920 x 1,080 |
| GRAPHICS | Intel® HD Graphics 620 | Intel® HD Graphics 520 | Intel® HD Graphics 620 |
| STORAGE | 500GB (7200rpm SATA) with shock absorbers 1TB (5400rpm SATA) with shock absorbers 128GB, 256GB, 512GB m.2 SATA SSD | ||
| OPTICAL DISK DRIVE | DVD SuperMulti Drive or None | ||
| POINTING DEVICE | TouchPad with multi-gesture support, Tile Keyboard AccuPoint + ClickPad with Backlit Keyboard (Optional) | TouchPad with multi-gesture support, Tile Keyboard (AccuPoint + ClickPad, Backlit Keyboard – standard on vPRO models) | TouchPad with multi-gesture support, Tile Keyboard with 10-key Numeric Pad |
| COMMUNICATIONS | Intel® Dual Band Wireless-AC 8265 802.11a/b/g/n/ac (2×2) WiFi and Bluetooth® 4.2 Combo, Intel® Ethernet Intel i219V Connection (10/100/1000Mbps) or Intel® Ethernet i219LM Connection with AMT (for vPro models) | ||
| BUILT-IN CAMERA | Built-in HD Web Camera with Dual Microphone | ||
| SOUND SYSTEM | Stereo speakers enhanced with DTS Studio Sound™ | ||
| INTERFACE | 3xUSB 3.0 (1x Sleep & Charge), VGA, HDMI, headphone/microphone combo, SD Card Reader (supports SD, SDHC, SDXC, microSD with adaptor), Docking Connector | ||
| BATTERY TYPE | 4-cell, 45Whr Li-Ion battery | ||
| AC ADAPTER | 45W Universal AC Adaptor | ||
| SECURITY AND PROTECTION | Trusted Platform Module (TPM) 2.0, 3D HDD Protection (HDD models only), Fingerprint Reader (Optional), SmartCard Reader (Optional), Spill-resistant keyboard, Cable lock port | ||
| PHYSICAL DIMENSIONS | 12.4 x 9 x .9 in/ 316 x 229 x 22.4mm | 13.3 x 9.6 x .9 in / 340.1 x 244.1 x 23.8mm | 14.9 x 10.2 x 379.0 x .9 in / 258 x 23.95mm |
| WEIGHT | Starting from 2.8 lbs / 1.27 kg (without ODD), starting from 3.1 lbs / 1.4 kg (with ODD). | Starting from 3.8 lbs / 1.74 kg (without ODD), starting from 4.1 lbs / 1.87 kg (with ODD). | Starting from 4.9 lbs /2.2 kg |
| WARRANTY | +Care ServiceSM Warranty 4-Year with On-Site | ||
| ENVIRONMENT | EPEAT™ Gold, ENERGY STAR™, RoHS-compliant | ||
| OPTIONAL ACCESSORIES | Enhanced port replicator and Dynadocks | ||
