Specifications – Dynabook X-Series
Learn more about the Sharp Dynabook X-Series of laptops.
| MODEL | Portégé X30-F | Tecra X40-F | ||
|---|---|---|---|---|
| PART NUMBER | PUR31U-0Y201H | PUR31U-0Y301H | PMR31U-0YY02H | PMR31U-0YX02H |
| OPERATING SYSTEM | Windows 10 Pro | |||
| PROCESSOR | Intel Core i5-8265U | Intel Core i7-8565U | Intel Core i5-8265U | Intel Core i7-8565U |
| GRAPHICS | Intel UHDGraphics 620 | |||
| MEMORY | 8 GB | 16 GB | 8 GB | 16 GB |
| STORAGE | 256 GB PCIe NVMe SSD | 512 GB PCIe NVMe SSD | 256 GB PCIe NVMe SSD | 512 GB PCIe NVMe SSD |
| DISPLAY | 13.3” FHCD (1920 x 1080) | 13.3” FHD (1920 x 1080) Touchscreen | 14.0” FHD (1920 x 1080) Touchscreen | 14.0” FHD (1920 x 1080) Touchscreen |
| AUDIO/VISUAL | Built-in Harman Kardon® stereo speakers DTS Audio Processing HD webcam with TruTalk® dual microphones | |||
| INPUT DEVICES | Premium spill-resistant, raised-tile, LED-backlit keyboard (black) Accupoint® pointing device Clickpad pointing device with multitouch control | |||
| COMMUNICATIONS | Intel Wireless-AC 9560 plus Bluetooth® | |||
| PORTS | HDMI® USB 3.2 Gen 1 USB Type-A port (w/ USB Sleep & Charge) 2 x USB 3.2 Gen 2 USB Type-C™ ports (supporting power, display & Thunderbolt™ 3) Headset jack (microphone input / headphone output) microSD™ Card slot | |||
| SECURITY | Trusted Platform Module (dTPM) v2.0 Fingerprint reader (Synaptics® SecurePad™) Infrared IR camera for Windows Hello™ face sign-in Slot for security lock | |||
| PHYSICAL DESCRIPTION | Onyx Blue Metallic Magnesium Alloy ToughBody chassis Dimensions (W x D x H): 12.4 x 8.9 x 0.63 in / 316 x 227 x 15.9 mm Weight: Starting at 2.3 lbs / 1.05 kg | Onyx Blue Metallic Magnesium Alloy ToughBody chassis Dimensions (W x D x H): 13.1 x 9.0 x 0.67 in / 332 x 228.9 x 16.9 mm Weight: Starting at 2.76 lbs / 1.25 kg | ||
| BATTERY | 3-cell 48 Wh Lithium Ion | |||
| BUNDLED ADAPTER | USB-C to HDMI / VGA / LAN / USB Adapter with Power Delivery (PD) Charging (included) | |||
| WARRANTY | +Care ServiceSM Warranty 4-Year with On-Site | |||
| OPTIONAL ACCESSORIES | PA5281U-1PRP – Thunderbolt 3 Dock PA5356U-1PRP – Dynabook USB-C Dock PA5270U-1PRP – USB-C to VGA Adapter with Power Delivery (PD) Charging PA5268U-1PRP – USB-C to LAN Adapter with Power Delivery (PD) Charging PA5279U-1ACA – USB-C 45W AC Adapter (5V / 9V / 15V / 20V) | |||
