Specifications – Canon imageFORMULA DR-C225 II Office Document Scanner
Learn more about the imageFORMULA DR-C225 II Office Document Scanner from Canon.
| MODEL NAME | imageFORMULA DR-C225 II |
|---|---|
| TYPE | Office Document Scanner |
| DOCUMENT FEEDING | Automatic or Manual |
| DOCUMENT SIZE | (U-Turn Path): Width: 2.0” – 8.5” |
| Length: 2.12” – 14.0”(Straight Path) : Width: 2.0” – 8.5” | |
| Length:2 .12” – 14.0” | |
| LONG DOCUMENT MODE | up to 118” |
| DOCUMENT WEIGHT | (U-Turn Path): 14 – 34 lb. Bond |
| Straight Path: 11 – 58 lb. Bond | |
| FEEDER CAPACITY | Up to 30 Sheets |
| GRAYSCALE | 8-bit |
| COLOR | 24-bit |
| LIGHT SOURCE | RGB LED |
| SCANNING ELEMENT | One-Line Contact Image Sensor (CMOS) |
| SCANNING MODES | Color, Grayscale, Black and White |
| OPTICAL RESOLUTION | Up to 600 dpi |
| OUTPUT RESOLUTION | 100/150/200/240/300/400/600 dpi |
| SCANNING SPEEDS | (Simplex / Duplex): BW/Grayscale /Color: Up to 25 ppm / Up to 50 ipm |
| INTERFACE | USB 2.0 |
| DIMENSIONS (H X W X D) | 8.7” x 11.8” x 6.1” (with trays closed) |
| WEIGHT | 5.95 lb. |
| POWER CONSUMPTION | 12.7 W or Less (Energy Saving Mode: 1.7 W or Less) |
| SUGGESTED DAILY VOLUME | Approx. 1,500 Scans |
| BUNDLED SOFTWARE | Windows: ISIS/TWAIN Driver; Canon CaptureOnTouch, Cardiris, Nuance eCopy PDF Pro Office |
| MAC: TWAIN Driver; Canon CaptureOnTouch | |
| SUPPORTED OPERATING SYSTEMS | Windows: Windows® 7/8/8.1/10 Service Pack 1 or later (32-bit/64-bit) or later, Windows® Server 2008 R2 2012/R2 2016 Service Pack 1 or later |
| MAC: 10.11 | |
| OPTIONS | Exchange Roller Kit, Flatbed Scanner Unit 102, Flatbed Scanner Unit 201, eCarePAK Extended Service |
| OTHER FEATURES | Automatic Color Detection, Automatic Page Size Detection, Automatic Resolution Setting, Background Smoothing, Character Emphasis, Color Dropout/ Red Color Enhance, Deskew, Duplex, Edge Emphasis, Face-Up Feeding, Folio Mode, Image Rotation, Long Document Mode, Moiré Reduction, MultiStream, Pre-Scan, Prevent Bleed-Through/Remove Background, Shadow Cropping / Removal, Simplex, Skip Blank Page, Text Enhancement, Text Orientation Recognition, Three-Dimensional Color Correction, Ultrasonic Double-Feed Detection, User Preferences |
