Specifications – HP LaserJet Pro M454 series
Learn more about the HP LaserJet Pro M454 Series.
| TECHNICAL SPECIFICATIOnS | M454nw | M454dn | M454dw |
|---|---|---|---|
| FUNCTIONS | |||
| DUPLEX PRINT OPTIONS | Manual (driver support provided) | Automatic (default) | |
| PRINT SPEED | Black (A4, normal): Up to 27 ppm; Black (letter, normal): Up to 28 ppm; Black (A4, duplex): Up to 24 ipm; Black (letter, duplex): Up to 25 ipm Color (A4, normal): Up to 27 ppm; Color (letter, normal): Up to 28 ppm; Color (A4, duplex): Up to 24 ipm; Color (letter, duplex): Up to 25 ipm | ||
| FIRST PAGE OUT | Black (A4, ready): As fast as 9.7 sec; Color (A4, ready): As fast as 11.3 sec; Black (A4, sleep): As fast as 13.8 sec; Color (A4, sleep): As fast as 15.3 sec | ||
| PRINT TECHNOLOGY | Laser | ||
| PRINT RESOLUTION | Black (best): 600 x 600 dpi, Up to 38, 400 x 600 enhanced dpi; Black (normal): 600 x 600 dpi, Up to 38, 400 x 600 enhanced dpi Color (best): 600 x 600 dpi, Up to 38, 400 x 600 enhanced dpi; Color (normal): 600 x 600 dpi, Up to 38, 400 x 600 enhanced dpi | ||
| PRINT RESOLUTION TECHNOLOGIES | HP ImageREt 3600, PANTONE® calibrated | ||
| PRINT CARTRIDGES NUMBER | The HP LaserJet Pro M454 series takes 4 cartridges (1 each black, cyan, magenta, yellow) | ||
| STANDARD PRINT LANGUAGES | HP PCL 6, HP PCL 5c, HP postscript level 3 emulation, PDF, URF, PWG Raster | HP PCL 6, HP PCL 5c, HP postscript level 3 emulation, PDF, URF, Native Office, PWG Raster | |
| PRINTER MANAGEMENT | HP Printer Assistant; HP Utility (Mac); HP Device Toolbox; HP Web JetAdmin Software; HP JetAdvantage Security Manager; HP SNMP Proxy Agent; HP WS Pro Proxy Agent; Printer Administrator Resource Kit for HP Universal Print Driver (Driver Configuration Utility – Driver Deployment Utility – Managed Printing Administrator) | ||
| CONNECTIVITY | |||
| STANDARD CONNECTIVITY | 1 Hi-Speed USB 2.0 port; 1 host USB at rear side; built-in Gigabit Ethernet 10/100/1000 Base-TX network port; 1 Wireless 802.11b/g/n/2.4/5 Ghz Wi-Fi radio | 1 Hi-Speed USB 2.0 port; 1 host USB at rear side; built-in Gigabit Ethernet 10/100/1000 Base-TX network port | 1 Hi-Speed USB 2.0 port; 1 host USB at rear side; built-in Gigabit Ethernet 10/100/1000 Base-TX network port; 1 Wireless 802.11b/g/n/2.4/5 Ghz Wi-Fi radio |
| MOBILE PRINT CAPABILITY | Apple AirPrint™; Google Cloud Print™; HP ePrint; HP Smart App and other mobile Apps; Mopria™ Certified; ROAM capable for easy printing; Wi-Fi® Direct printing | ||
| NETWORK CAPABILITIES | Yes, via built-in 10/100/1000Base-Tx Ethernet, Gigabit; Auto-crossover Ethernet; Authentication via 802.1x | ||
| WIRELESS CAPABILITY | Yes, built-in dual-band Wi-Fi; Authentication via WEP, WPA/WPA2, WPA Enterprise; Encryption via AES or TKIP; WPS; Wi-Fi Direct; Bluetooth Low-Energy | Yes, built-in dual-band Wi-Fi; Authentication via WEP, WPA/WPA2, WPA Enterprise; Encryption via AES or TKIP; WPS; Wi-Fi Direct; Bluetooth Low-Energy | |
| MEMORY | Standard: 256 MB NAND Flash, 512 MB DRAM; Maximum: 256 MB NAND Flash, 512 MB DRAM | Standard: 512 MB NAND Flash, 512 MB DRAM; Maximum: 512 MB NAND Flash, 512 MB DRAM | |
| DUTY CYCLE | Up to 50,000 pages; Recommended monthly page volume: 750 to 4,000 pages | ||
| PROCESSOR SPEED | 1200 MHz | ||
| PAPER HANDLING | |||
| INPUT | 50-sheet multipurpose tray, 250-sheet input tray | ||
| OUTPUT | 150-sheet output bin | ||
| MEDIA TYPE | Paper (bond, brochure, colored, glossy, letterhead, photo, plain, preprinted, prepunched, recycled, rough), postcards, labels, envelopes | ||
| MEDIA WEIGHT | Tray 1: 16 lb. Bond to 47 lb. Bond (60 to 175 g/m²) [up to 53 lb. Bond (200 g/m²) with postcards and HP Color laser glossy photo papers]; Tray 2: 16 lb. Bond to 43 lb. Bond (60 to 163 g/m²) [up to 47 lb. Bond (175 g/m²) with postcards, up to 53 lb. Bond (200 g/m²) HP Color laser glossy photo papers]: optional Tray 3: 6 lb. Bond to 43 lb. Bond (60 to 163 g/m²) [up to 47 lb. Bond (175 g/m²) with postcards, up to 40 lb. Bond (150 g/m²) Glossy media] | Tray 1: 16 lb. Bond to 47 lb. Bond (60 to 175 g/m²) [up to 53 lb. Bond (200 g/m²) with postcards and HP Color laser glossy photo papers]; Tray 2: 16 lb. Bond to 43 lb. Bond (60 to 163 g/m²) [up to 47 lb. Bond (175 g/m²) with postcards, up to 53 lb. Bond (200 g/m²) HP Color laser glossy photo papers]: optional Tray 3: 16 lb. Bond to 43 lb. Bond (60 to 163 g/m²) up to 47 lb. Bond (175 g/m²) with postcards, up to 40 lb. Bond (150 g/m²) Glossy media]; Automatic duplexer: 16 lb. Bond to 43 lb. Bond (60 to 163 g/m²) | |
| MEDIA SIZES CUSTOM | Tray 1: 3 x 5 in (76.2 x 127) to 8.5 x 14 in (215.9 x 355.6 mm);Tray 2, optional Tray 3: 4.13 x 5.85 in(104.9 x 148.59) to 8.5 x 14 in (215.9 x 355.6 mm) | ||
| DIMENSIONS (W X D X H) | 16.2 x 17.8 x 11.6 in (412 x 453 x 295 mm) | 16.2 x 18.5 x 11.6 in (412 x 469 x 295 mm) | |
| WEIGHT | 38.6 lb (17.5 kg) | 41.7 lb (18.9 kg) | |
| WHAT’S IN THE BOX | HP Color LaserJet Pro M454nw; 4 preinstalled Introductory HP LaserJet Toner cartridges (Black, Cyan, Magenta, Yellow: ~1200 pages); In-box documentation (Getting Started Guide, Install Poster), regulatory flyer; Internet connection is required to set up the printer. HP printer software is available at http://www.hp.com/support; Power cord; USB cable | HP Color LaserJet Pro M454dn; 4 preinstalled Introductory HP LaserJet Toner cartridges (Black, Cyan, Magenta, Yellow: ~ 1200 pages); In-box documentation (Getting Started Guide, Install Poster), regulatory flyer; Internet connection is required to set up the printer. HP printer software is available at http://www.hp.com/support; Power cord; USB cable (AP only) | HP Color LaserJet Pro M454dw; 4 preinstalled Introductory HP LaserJet Toner cartridges (Black, Cyan, Magenta, Yellow: ~1200 pages); In-box documentation (Getting Started Guide, Install Poster), regulatory flyer, warranty card (China, Mexico); Internet connection is required to set up the printer. HP printer software is available at http://www.hp.com/support; Power cord; USB cable. |
| WARRANTY FEATURES | The HP LaserJet Pro M454 series has a one-year Bench/Depot Repair warranty. Warranty and support options vary by product, country and local legal requirements. Contact your Contractual Vendor or go to hp.com/support to learn about HP award winning service and support options in your region. (wty code 4E; wty ID A033) | ||
| SYSTEMS | |||
| COMPATIBLE OPERATING SYSTEMS | Windows Client OS (32/64 bit), Win10, Win8.1, Win 8 Basic, Win8 Pro, Win8 Enterprise, Win8 Enterprise N, Win7 Starter Edition SP1, UPD Win7 Ultimate, Mobile OS, iOS, Android, Mac, Apple® macOS Sierra v10.12, Apple® macOS High Sierra v10.13, Apple® macOS Mojave v10.14, Discrete PCL6 Printer Driver, For more information on the supported operating systems, click here, Enter your product name and search, Click on User Guides and enter your product name and search for User Guide, Search for your (Product Name) User Guide, Search for the Supported Operating Systems section, UPD PCL6 / PS Printer Drivers, Supported Operating systems. For more information on the supported operating systems visit the HP website or contact your sales representative. | ||
| MINIMUM SYSTEM REQUIREMENTS | PC: 2 GB available hard disk space, Internet connection, USB port, Internet browser. For additional OS hardware requirements see microsoft.com; Mac: 2 GB available hard drive space, Internet connection or USB port, OS hardware requirements see apple.com | ||
| FONTS AND TYPEFACES | 84 scalable TrueType fonts | ||
| CONTROL PANEL | 2-line backlit LCD graphic display; 5 buttons (Cancel, Select, Reverse, Right/Left arrows); LED indicator lights (Attention, Ready) | 2.7-inch intuitive color touchscreen; 3 Buttons (Home, Help, Back) | |
| POWER | Power supply type: Internal (built-in) Power Supply; Power supply required: 110-volt input voltage: 110 to 127 VAC (+/- 10%), 60 Hz (+/- 3 Hz); 220-volt input voltage: 220 to 240 VAC (+/- 10%), 50/60Hz (+/- 3 Hz) (Not dual voltage, power supply varies by part number with # Option code identifier); Power consumption: 550 watts (active printing), 17 watts (ready), 0.9 watts (sleep), 0.9 watts (HP auto-off/auto-on), 0.07 watts (auto-off/manual-on), 0.07 watts (off); Typical Electricity Consumption number: 1.144 kWh/Week (Energy Star), 1.046 kWh/week (Blue Angel) | Power supply type: Internal (built-in) Power Supply; Power supply required: 110-volt input voltage: 110 to 127 VAC (+/- 10%), 60 Hz (+/- 3 Hz); 220-volt input voltage: 220 to 240 VAC (+/- 10%), 50/60Hz (+/- 3 Hz) (Not dual voltage, power supply varies by part number with # Option code identifier); Power consumption: 550 watts (active printing), 17 watts (ready), 0.9 watts (sleep), 0.9 watts (HP auto-off/auto-on), 0.07 watts (auto-off/manual-on), 0.07 watts (off); Typical Electricity Consumption number: 1.046 kWh/Week (Blue Angel); 0.394 kWh/Week (Energy Star 3.0) | |
| ACOUSTIC | Acoustic power emissions: 6.2 B(A) ; Acoustic power emissions (ready): 3.4 B(A) ; Acoustic pressure emissions bystander (active, printing): 48 dB(A) ; Acoustic pressure emissions bystander (ready): 14 dB(A) | Acoustic power emissions: 6.2 B(A) ; Acoustic power emissions (ready): 3.4B(A) ; Acoustic pressure emissions bystander (active, printing): 48 dB(A) ; Acoustic pressure emissions bystander (ready): 14 dB(A) | |
| ENVIRONMENTAL RANGES | The following ranges are recommended for the HP LaserJet Pro M454 series:Operating temperature range: 59 to 90.5° F (15 to 32.5° C); Recommended operating temperature: 59 to 80.6° F (15 to 27° C); Operating humidity range: 10 to 80% RH (non-condensing); Recommended operating humidity range: 30 to 70% RH (non-condensing) | ||
| ENERGY EFFICIENCY COMPLIANCE | CECP | ENERGY STAR® qualified; EPEAT® Silver; CECP | |
| ENERGY STAR QUALIFIED | No | Yes | |
| SECURITY MANAGEMENT | Secure Boot; Secure Firmware Integrity; Runtime Code Integrity; password protected EWS; secure browsing via SSL/TLS 1.0; TLS 1.1; TLS 1.2; IPP over TLS; Network: enable/disable network ports and features; unused protocol and service disablement; SNMPv1; SNMPv2; and SNMPv3; community password change; HP ePrint: HTTPS with certificate validation; HTTP Basic Access Authentication; SASL authentication; Firewall and ACL; control panel lock; certificates configuration; UPD PIN printing; Syslog; signed firmware; administrator settings; 802.1x authentication (EAP-TLS, and PEAP); authentication via WEP; WPA/WPA2 Personal; WPA2-enterprise; encryption via AES or TKIP; Encrypted data storage; Secure data erase; Automatic firmware updates; Secure Encrypted Print via optional job storage; Compatible with optional HP JetAdvantage Security Manager; IPPS | Secure Boot, Secure Firmware Integrity, Runtime Code Integrity, password protected EWS, secure browsing via SSL/TLS 1.0, TLS 1.1, TLS 1.2; IPP over TLS; Network: enable/disable network ports and features, unused protocol and service disablement, SNMPv1, SNMPv2, and SNMPv3, community password change; HP ePrint: HTTPS with certificate validation, HTTP Basic Access Authentication, SASL authentication; Firewall and ACL; control panel lock, certificates configuration, UPD PIN printing, Syslog, signed firmware, administrator settings, 802.1x authentication (EAP-TLS, and PEAP); Encrypted data storage; Secure data erase; Automatic firmware updates; Secure Encrypted Print via optional job storage, Compatible with optional HP JetAdvantage Security Manager | Secure Boot; Secure Firmware Integrity; Runtime Code Integrity; password protected EWS; secure browsing via SSL/TLS 1.0; TLS 1.1; TLS 1.2; IPP over TLS; Network: enable/disable network ports and features; unused protocol and service disablement; SNMPv1; SNMPv2; and SNMPv3; community password change; HP ePrint: HTTPS with certificate validation; HTTP Basic Access Authentication; SASL authentication; Firewall and ACL; control panel lock; certificates configuration; UPD PIN printing; Syslog; signed firmware; administrator settings; 802.1x authentication (EAP-TLS, and PEAP); authentication via WEP; WPA/WPA2 Personal; WPA2-enterprise; encryption via AES or TKIP; Encrypted data storage; Secure data erase; Automatic firmware updates; Secure Encrypted Print via optional job storage; Compatible with optional HP JetAdvantage Security Manager; IPPS |
| SAFETY APPROVALS AND REQUIREMENTS | IEC 60950-1:2005 +A1:2009+A2:2013/EN 60950-1:2006 +A11:2009+A1:2010+A12:2011+A2:2013; IEC 60825-1:2014/EN 60825-1:2014 (Class 1 Laser/LED Product); IEC 62479: 2010/EN 62479: 2010 | ||
| SUPPORTED NETWORK PROTOCOLS | TCP/IP, IPv4, IPv6; Print: TCP-IP port 9100 Direct Mode, LPD (raw queue support only), Web Services Printing, HP ePrint, Apple AirPrint™, Google Cloud Print 2.0, Mopria, IPP Print; Discovery: SLP, Bonjour, Web Services Discovery; IP Config: IPv4 (BootP, DHCP, AutoIP, Manual), IPv6 (Stateless Link-Local and via Router, Statefull via DHCPv6), SSL Security and Certificate management; Management: SNMPv1, SNMPv2, SNMPv3, HTTP/HTTPS, Syslog, FTP FW Download | ||
