Specifications – Canon imageCLASS X LBP1127C
For more information on the Canon imageCLASS X LBP1127C , view the brochure.
| MAIN UNIT | |
|---|---|
| CORE FUNCTIONS | Standard: Print |
| PROCESSOR | Canon Custom Processor |
| CONTROL PANEL | 5″ Color Touch Panel |
| MEMORY | 1 GB |
| STANDARD INTERFACE CONNECTION | USB 2.0 x2 (Host), USB 2.0 x1 (Device) High-Speed, 10/100/1000Base-T Ethernet (Network), Wi-Fi 802.11b/g/n, Wi-Fi® Direct Connection, Near Field Communication |
| PAPER CAPACITY (LETTER, 20 LB. BOND) | Standard: 300 Sheets |
| Maximum:850 Sheets | |
| PAPER SOURCES (LETTER, 20 LB. BOND) | Standard: 250-sheet Paper Cassette 50-sheet Stack Bypass |
| Optional: 550-sheet Paper Cassette (Cassette Unit AF-1) | |
| PAPER OUTPUT CAPACITY (LETTER, 20 LB. BOND) | 75 Sheets |
| SUPPORTED MEDIA TYPES | Cassettes: Thin, Plain, Recycled, Color, Thick, Coated, Label, Letter, Envelopes (10 Envelopes) |
| Stack Bypass: Thin, Plain, Recycled, Color, Thick, Coated, Label, Letter, Envelope (1 Envelope) | |
| SUPPORTED MEDIA SIZES | Cassettes: Letter, Legal, Statement, Executive Envelope: COM10, Monarch, C5, DL Custom (Min. 3″ x 5″ to Max. 8.5″ x 14″) |
| Stack Bypass: Letter, Legal, Statement, Executive Envelope: COM10, Monarch, C5, DL Custom (Min. 3″ x 5″ to Max. 8.5″ x 14″) | |
| SUPPORTED MEDIA WEIGHTS | Cassettes: 16 lb. Bond to 53 lb. Bond (60 to 200 g/m2) |
| Stack Bypass: 16 lb. Bond to 53 lb. Bond (60 to 200 g/m2) | |
| WARM-UP TIME | From Power On: 13 Seconds or Less |
| From Sleep Mode:6.1 Seconds or Less | |
| DIMENSIONS (W x D x H) | imageCLASS X LBP1127C: |
| Standard (Desktop): 19″ x 18.8″ x 15.2″ (484 mm x 477 mm x 385 mm) | |
| Box: 23.1″ x 23.2″ x 17.5″ (586 mm x 590 mm x 444 mm) | |
| INSTALLATION SPACE (W x D x H) | Standard (Desktop): 21.6″ x 43.8″ x 25.8″ (549 mm x 1113 mm x 655 mm) |
| Fully Configured: 21.6″ x 43.8″ x 31.1″ (549 mm x 1113 mm x 790 mm) | |
| WEIGHT | Unit: Approx. 47.8 lb. (22.0 kg) |
| Boxed Weight: Approx. 53.5 lb. (24.0 kg) | |
| SUPPORTED OS | Windows® 7/Windows 8.1/Windows 10/Windows Server 2008/Windows Server 2008 R2/Windows Server 2012/ Windows Server 2012 R2/Windows Server 2016 /Mac OS X v10.9.5 (or later) |
| PRINT SPECIFICATIONS | |
|---|---|
| PRINTING METHOD | Laser Beam Printing |
| PRINT SPEED | Up to 28 ppm (Letter); Up to 22.9 ppm (Legal) |
| FIRST PRINT-OUT TIME | Approx. 7.5 Seconds |
| RECOMMENDED MONTHLY PAGE VOLUME | 750 – 4,000 Pages |
| PRINT RESOLUTION (dpi) | 600 x 600 |
| STANDARD PAGE DESCRIPTION LANGUAGES | UFR II, PCL®6, PCL®5, Adobe PostScript 3® |
| DOUBLE-SIDED PRINTING | Automatic (Standard) |
| DIRECT PRINT | Available from USB Memory (JPEG, TIFF, PDF) |
| PRINTING FROM MOBILE AND CLOUD-BASED SERVICES1 | A range of standard and optional software and MEAP- based solutions (including AirPrint, Mopria, Google Cloud Print, Canon PRINT Business, anduniFLOW Mobile Printing) are available for the imageCLASS X LBP1127C to provide printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements. Pleasecontact your sales representativefor further information. |
| FONTS | PCL:93 Fonts |
| PS :136 Fonts | |
| PRINT FEATURES | Secure Print, Page Border, Header/Footer, Page Layout, Two-sided Printing, Collating, Booklet Printing, Grouping, Mixed Paper Sizes/Orientations |
| SECURITY SPECIFICATIONS | |
|---|---|
| AUTHENTICATION | Standard:Embedded Universal Login Manager, Department ID Authentication |
| Optional:uniFLOW, uniFLOW Online | |
| DATA | Standard:Verify System at Startup |
| NETWORK | Standard:IP/MAC Address Filtering, IPSEC, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X(Wired Only), IPv6, SMTP Authentication, POP Authentication, POP Authentication before SMTP |
| DOCUMENT | Standard: Secure Print |
| WI-FI® AUTHENTICATION METHODS | Wi-Fi Infrastructure Mode:WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES) |
| Wi-Fi Access Point:WPA2-PSK (AES) | |
| ENVIRONMENTAL SPECIFICATIONS | |
|---|---|
| OPERATING ENVIRONMENT | The imageCLASS X LBP1127C should be operated within the following environments: Temperature:50 to 86º F; |
| Humidity:20 to 80% RH (no condensation) | |
| POWER REQUIREMENTS | AC 120-127 V:6.5 A, 60 Hz |
| POWER CONSUMPTION | Maximum:Approx. 1490 W |
| Standby:Approx. 19.6 W | |
| Sleep Mode:Approx. 0.6 W | |
| Typical Electricity Consumption (TEC) Rating:0.32 kWh | |
| STANDARDS | ENERGY STAR® Qualified, Rated EPEAT Silver |
| CONSUMABLES | |
|---|---|
| TONER | Toner T09 Black – Yields 7,600 Pages |
| Toner T09 Cyan – Yields 5,900 Pages | |
| Toner T09 Magenta – Yields 5,900 Pages | |
| Toner T09 Yellow – Yields 5,900 Pages | |
